DS-2CE55C2P(N)-VFIR3-720TVL Vari-focal IR Dome Camera


Image Sensor

1/3” PICADIS

Signal System

PAL/NTSC

Effective Pixels

1280 (H) × 960 (V)

Min. Illumination

0.1Lux @ (F1.2,AGC ON),0 Lux with IR
0.14Lux @ (F1.4,AGC ON),0 Lux with IR

Shutter Time

1/25(1/30) s to 1/25,000(1/30,000) s

Lens

2.8-12 mm @ F1.4
Angle of view: 80° – 27.2°

Lens Mount

φ14

Adjustment Range

Pan: 0 – 360°, Tilt: 0 – 90°, Rotation: 0 – 360°

Day& Night

IR cut filter with auto switch

Horizontal Resolution

720TVL

Synchronization

Internal Synchronization

Video Output

1Vp-p Composite Output (75Ω/BNC)

S/N Ratio

More than 62 dB

Operating Conditions

-40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)

Power Supply

12 V DC±10%

Power Consumption

Max. 4 W(Max. 5 W with IR cut filter on)

Weather Proof

IP66

IR Range

Approx 30 to 40 meters

Dimension

134.2×123.9×88.1mm(5.28”×4.88”×3.47”)

Weight

800g (1.76l lbs)
