Matrix Cosec Door PVR Palm Vein Reader


Biometric devices used for access control and time-attendance helps to enhance security and productivity of an organization. However, most of them have to compromise between the security it offers and convenience it provides. The compromise could be on having lower accuracy, higher rejection ratio, needing physical contact, hygiene concern and possibility of copying the biometric pattern.

Biometric devices used for access control and time-attendance helps to enhance security and productivity of an organization. However, most of them have to compromise between the security it offers and convenience it provides. The compromise could be on having lower accuracy, higher rejection ratio, needing physical contact, hygiene concern and possibility of copying the biometric pattern.

COSEC DOOR PVR is a highly secure and contactless biometric device that works by reading the vascular pattern of the palm. These patterns are unique to each individual and exists underneath the skin layer so they cannot be forged thereby making it more secure than any other biometric device. Being contactless and technologically advanced, it is appropriate for places like hospitals, chemical industries, nuclear stations, factories, corporate houses, R&D centers, financial institutes and many others where security and hygiene cannot be compromised.



Features

  • *  Hi-tech Palm Vein Reader
  • *  Access Control and Time-Attendance
  • *  Built-in Wi-Fi Module
  • *  3G, 2G, GSM and CDMA Connectivity
  • *  20,000 Palm Templates
  • *  1,00,000 Events Buffer
  • *  Ethernet and USB Interface
  • *  Dot Matrix lcd and Touch Sense Keypad
  • *  Support RFID Card and PIN
  • *  1:1, 1:N and 1:G Verification
  • *  Detachable Hand Guide



Benefits

  • Highly Secured for Access Control Application
  • Higher Authentication Accuracy
  • Cannot be Forged
  • Contactless Design Minimizes Hygiene Concerns and Psychological Resistance



Connectivity Diagram



Cosec Door PVR connecting



Credential Support

Card, Palm Vein & PIN

User Capacity

10,000

Templates per User

Up to 2

Palm Template Capacity

20,000 Templates

Cards per User

2 Any Type)

Type of Card

Smart and Proximity

LCD (128x64 Dot-Matrix)

Yes

Touch Sense Keys (16)

Yes

Verification Method

1:1, 1:N and 1:G

Events Buffer

1,00,000

Wireless Connectivity

Wi-Fi, 2G, 3G, GPRS, CDMA

USB

2 Ports

Communication

Ethernet

Communication Speed

10/100Mbps on Ethernet

Tamper Detection

Yes

Buzzer

Yes

LED Indication

4 LEDs (Status, Alarm, Allowed and Denied)

External Reader

1 Port for Card Reader

External Reader Interfaces

RS-232 and Wiegand

External Reader Power

12VDC@0.5A

Exit Switch Port

Yes

Door Status Sense

Programmable NO, NC, Supervised

Door Lock Relay

Relay SPDT, Form C, 1A@30VDC

Door Lock Power

Internal 12VDC@0.5A or External

Auxiliary Input Port

Programmable NO, NC, Supervised

Auxiliary Output Relay

Relay SPDT, Form C, 1A@30VDC

CPU

1 GHz ARM Cortex A-8 based processor

Memory

256MB Flash + 512MB DDR3 RAM

Input Power

12VDC@2A

Dimensions

(WхHхD) 100×220×55mm (3.9”х8.7”х2.2”)

Weight

0.49Kg (1.07Lbs)

Environment

0°C to +50°C (32°F to 122°F), 5% to 95% RH Non-Condensing
